General Specifications

Housing

• Architectural, low profile decorative design.
• Die-cast aluminum housing with an efficient heat sink.
• Enclosure rated Ip65 per IEC 60529, suit for outdoor use.
• UV resistant polycarbonate lens.
• Universal pattern knockouts on the backplate for the junction box.
• 1/2” threaded conduit access on the top surface.
• Black, white, dark bronze, silver UV resistant powder paint finish.

Electrical

• AC 120-37V 60Hz operation, class 2 driver.
• Switching power circuits with high power factor and efficiency.
• Test switch and charge indicator.
• Long-life, maintenance-free, rechargeable Ni-Cad battery.
• 24 hours recharge after 90 minutes discharge.

Illumination

• LG SMD 3535 LED 3000K/4000K/5000K, 8pcs,
• LED CRI >70, L70>72,000 hours.
• Max. 1600lm output from AC mode,>100lm/W,
• Max 600lm output from ACEM model emergency mode.
• Max 500lm output from ACEM-CL model emergency mode.
